XC6VHX255T-1FFG1923I
480 I/O ports on the device allow for more efficient data transmission. A basic construction block has 253440 logic cells or components. FPGA chips require a power source of 1V volts to function. There are 480 outputs incorporated into a device like this. There have been 1923 terminations in all. Having said that, this FPGA could be able to operate very well in accordance with its requirements if it is put in Surface Mount. The device is powered by an 11.2/2.5V battery. This module has a maximum working temperature of 100°C. Higher than the working temperature should be -40°C. It is a multifunctional tool with a total of 1923 pins.
Integrated interface blocks for PCI Express® designs
Flexible configuration options
GTX transceivers: up to 6.6 Gb/s
System Monitor capability on all devices
Flexible configuration options
Telecommunication
Wireless Communications
Voice recognition
Embedded Vision
Audio
Product information on this page is provided for identification and sourcing reference purposes. A product listing does not indicate that VEMEKO currently holds physical inventory of the listed part number. Availability, manufacturer, source, date code, packaging, condition and lead time are confirmed separately at the quotation stage.
AMD, Xilinx, Zynq, Kintex, Virtex and other related trademarks are the property of Advanced Micro Devices, Inc. or its affiliates. VEMEKO is an independent electronic component sourcing company and is not represented as an authorized distributor of AMD unless expressly stated and documented for a specific transaction.
| Specifications | Value |
| Mount | Surface Mount |
| Package / Case | FCBGA |
| JESD-609 Code | e1 |
| Pbfree Code | yes |
| Moisture Sensitivity Level (MSL) | 4 |
| Number of Terminations | 1923 |
| ECCN Code | 3A991.D |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -40°C |
| HTS Code | 8542.39.00.01 |
| Subcategory | Field Programmable Gate Arrays |
| Technology | CMOS |
| Terminal Position | BOTTOM |
| Terminal Form | BALL |
| Peak Reflow Temperature (Cel) | 245 |
| Supply Voltage | 1V |
| Terminal Pitch | 1mm |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Pin Count | 1923 |
| JESD-30 Code | S-PBGA-B1923 |
| Number of Outputs | 480 |
| Qualification Status | Not Qualified |
| Supply Voltage-Max (Vsup) | 1.05V |
| Power Supplies | 11.2/2.5V |
| Temperature Grade | INDUSTRIAL |
| Supply Voltage-Min (Vsup) | 0.95V |
| Number of I/O | 480 |
| RAM Size | 2.3MB |
| Clock Frequency | 1098MHz |
| Number of Inputs | 480 |
| Programmable Logic Type | FIELD PROGRAMMABLE GATE ARRAY |
| Number of Logic Elements/Cells | 253440 |
| Number of Logic Blocks (LABs) | 19800 |
| Combinatorial Delay of a CLB-Max | 5.08 ns |
| Height Seated (Max) | 3.85mm |
| Length | 45mm |
