XC6VHX380T-2FFG1924I
With integrated software and hardware components, the XC6VHX380T-2FFG1924I is a Virtex®-6 FPGA for Targeted Design Platforms that enables designers to concentrate on innovation as soon as their development cycle begins. Manufacturers can use the gadget to build systems that can be changed as needed. In addition, the chip is used in the fields of wireless communications, medical electronics, consumer electronics, digital television, industrial motor control, and aerospace and military.
1.2 to 2.5V /O operation
Source-synchronous interfacing using ChipSyncTM technology
Digitally controlled impedance (DCI) active termination
Flexible fine-grained /O banking
High-speed memory, interface support with the integrated write-levelling capability
40 nm copper CMOS process technology
1.0V core voltage (-1, -2, -3 speed grades only)
Lower-power 0.9V core voltage option (-1L speed grade only)
High signal-integrity flip-chip packaging is available in
standard or Pb-free package options
Internet of Things
Medical Equipment
Consumer Electronics
Aerospace & Defense
Telecommunication
| Specifications | Value |
| Contact Plating | Copper, Silver, Tin |
| Mount | Surface Mount |
| Mounting Type | Surface Mount |
| Package / Case | 1924-BBGA, FCBGA |
| Number of Pins | 1924 |
| Operating Temperature | -40°C~100°C TJ |
| Packaging | Tray |
| Published | 2008 |
| Series | Virtex®-6 HXT |
| JESD-609 Code | e1 |
| Pbfree Code | yes |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | 4 (72 Hours) |
| ECCN Code | 3A001.A.7.B |
| Terminal Finish | Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5) |
| Subcategory | Field Programmable Gate Arrays |
| Technology | CMOS |
| Voltage - Supply | 0.95V~1.05V |
| Terminal Position | BOTTOM |
| Terminal Form | BALL |
| Peak Reflow Temperature (Cel) | 245 |
| Supply Voltage | 1V |
| Terminal Pitch | 1mm |
| Reach Compliance Code | not_compliant |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Base Part Number | XC6VHX380T |
| Number of Outputs | 640 |
| Qualification Status | Not Qualified |
| Number of I/O | 640 |
| RAM Size | 3.4MB |
| Propagation Delay | 220 ps |
| Turn On Delay Time | 220 ps |
| Programmable Logic Type | FIELD PROGRAMMABLE GATE ARRAY |
| Number of Logic Elements/Cells | 382464 |
| Total RAM Bits | 28311552 |
| Number of LABs/CLBs | 29880 |
| Speed Grade | 2 |
