XC6VHX380T-3FF1155C
The I/Os are created to make the data transfer more organized. There are 382464 logic elements or cells that make up a fundamental building block. One volt serves as the power source for it. This Field Programmable Gate Array component is a member of that family. The device has 440 outputs built in to provide you with the most versatility possible. On FPGA chips, there are 1156 terminations altogether. The RAM si3.4MBe of this FPGA module must increase to 3.4MB GB in order to ensure that the application runs as intended. This FPGA will function flawlessly in accordance with its specifications as long as it is put in Surface Mount.
Digitally controlled impedance (DCI) active termination
Flexible fine-grained I/O banking
High-speed memory interface support with integrated write-leveling capability
Optional pipelining
Software-defined radios
Solar Energy
Automotive Applications
Military Temperature
Product information on this page is provided for identification and sourcing reference purposes. A product listing does not indicate that VEMEKO currently holds physical inventory of the listed part number. Availability, manufacturer, source, date code, packaging, condition and lead time are confirmed separately at the quotation stage.
AMD, Xilinx, Zynq, Kintex, Virtex and other related trademarks are the property of Advanced Micro Devices, Inc. or its affiliates. VEMEKO is an independent electronic component sourcing company and is not represented as an authorized distributor of AMD unless expressly stated and documented for a specific transaction.
| Specifications | Value |
| Mount | Surface Mount |
| Package / Case | FCBGA |
| JESD-609 Code | e0 |
| Number of Terminations | 1156 |
| Terminal Finish | TIN LEAD |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | 0°C |
| Subcategory | Field Programmable Gate Arrays |
| Technology | CMOS |
| Terminal Position | BOTTOM |
| Terminal Form | BALL |
| Supply Voltage | 1V |
| Terminal Pitch | 1mm |
| Pin Count | 1156 |
| JESD-30 Code | S-PBGA-B1156 |
| Number of Outputs | 440 |
| Operating Supply Voltage | 1V |
| Supply Voltage-Max (Vsup) | 1.05V |
| Power Supplies | 11.2/2.5V |
| Temperature Grade | OTHER |
| Number of I/O | 440 |
| RAM Size | 3.4MB |
| Clock Frequency | 1412MHz |
| Propagation Delay | 190 ps |
| Number of Inputs | 440 |
| Programmable Logic Type | FIELD PROGRAMMABLE GATE ARRAY |
| Number of Logic Elements/Cells | 382464 |
| Number of Logic Blocks (LABs) | 29880 |
| Speed Grade | 3 |
| Radiation Hardening | No |
| RoHS Status | RoHS Compliant |
