XC6VHX565T-1FF1923C
The I/Os are created to make the data transfer more organized. A computer's essential building block is its logic components or cells. This FPGA module may be mounted to the development board via a Surface Mount connection. FPGA chips require a supply voltage of 0.95V–1.05V to operate. The device includes 720 outputs in total. It requires 1923 pins, which have been created to make it function. This FPGA contains 29880 integrated LABs and CLBs. Having said that, this FPGA could be able to operate very well in accordance with its requirements if it is put in Surface Mount. A battery measuring 11.2/2.5V that comes with the device powers it.
Advanced, high-performance FPGA Logic
1.0V core voltage (-1, -2, -3 speed grades only)
Integrated interface blocks for PCI Express® designs
Flexible configuration options
Voice recognition
Embedded Vision
Audio
Enterprise networking
| Specifications | Value |
| Mount | Surface Mount |
| Package / Case | FCBGA |
| Published | 2008 |
| JESD-609 Code | e0 |
| Pbfree Code | no |
| Part Status | Active |
| Terminal Finish | TIN LEAD |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | 0°C |
| Subcategory | Field Programmable Gate Arrays |
| Technology | CMOS |
| Terminal Position | BOTTOM |
| Terminal Form | BALL |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Supply Voltage | 1V |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Number of Outputs | 720 |
| Qualification Status | Not Qualified |
| Operating Supply Voltage | 1V |
| Temperature Grade | OTHER |
| Number of I/O | 720 |
| RAM Size | 4MB |
| Number of Inputs | 720 |
| Programmable Logic Type | FIELD PROGRAMMABLE GATE ARRAY |
| Number of Logic Elements/Cells | 566784 |
| Number of Logic Blocks (LABs) | 44280 |
| Speed Grade | 1 |
| Combinatorial Delay of a CLB-Max | 5.08 ns |
| Height Seated (Max) | 3.85mm |
| Length | 45mm |
| Width | 45mm |
| RoHS Status | RoHS Compliant |
