The XC7A15T-1CSG324C is an embedded field programmable gate array (FPGA) from the Artix-7 series. It contains 210 I/O pins and the capacity to be programmed. The FPGA offers great performance and versatility because to its 1300 LABs/CLBs (Logic Array Blocks/Configurable Logic Blocks) and 16640 logic elements/cells. With a voltage supply range of 0.95V to 1.05V, it runs with a total RAM capacity of 921600 bits. The 324-LFBGA, CSPBGA package of the XC7A15T-1CSG324C is designed for surface mount mounting type. It is an active product from AMD that acts between 0°C and 85°C. The FPGA is frequently employed in numerous embedded applications that call for programmable logic and quick processing power. View Substitutes & Alternatives, datasheets, stock, pricing from Authorized Distributors, as well as other FPGAs goods, at www.vemeko.com.
Three Pmod standard ports
The Artix®-7 has higher system performance, programmable system integration, and reduced BOM costs.
Reduction in total power (65% less static power and 50% less power than 45nm generation devices)
Design productivity that is increased more quickly, scalable, optimized architecture, extensive tools, and IP
Modern 28nm, high-k metal gate (HKMG), high performance, low power (HPL) technology
Phase-locked loop and mixed mode clock managers are combined in effective clock management tiles (CMT).
Options for lidless flip-chip packages, low cost wire bonding, and AXI IP (analogue mixed signal integration)
Consumer electronics
Medical devices
Defense applications
The embedded OEM
Software defined radio
Any-to-any connectivity
Programmable logic controller
Specification | Value |
Category | Integrated Circuits (ICs) Embedded FPGAs (Field Programmable Gate Array) |
Mfr | AMD |
Series | Artix-7 |
Package | Tray |
Product Status | Active |
DigiKey Programmable | Not Verified |
Number of LABs/CLBs | 1300 |
Number of Logic Elements/Cells | 16640 |
Total RAM Bits | 921600 |
Number of I/O | 210 |
Voltage - Supply | 0.95V ~ 1.05V |
Mounting Type | Surface Mount |
Operating Temperature | 0°C ~ 85°C (TJ) |
Package / Case | 324-LFBGA, CSPBGA |
Supplier Device Package | 324-CSPBGA (15x15) |
Base Product Number | XC7A15 |
