XC7A15T-2CSG324I

XC7A15T-2CSG324I Overview

XC7A15T-2CSG324I has 210 I/Os, 16640 logic cells, and 921600 RAM bits. It is a series FPGA IC. It is placed utilizing surface mount technology and functions over a voltage range of -40°C to 100°C. The family name is XC7A15, and the package's identification code is 324-LFBGA CSPBGA. The FPGA is a well-known product on the market and is utilized in many different electronic gadgets. It is REACH unaffected and the expected production lead time is 51 weeks. View Substitutes & Alternatives, datasheets, stock, pricing from Authorized Distributors, as well as other FPGAs goods, at www.vemeko.com.

XC7A15T-2CSG324I Features

• Real 6-input lookup table (LUT)-based advanced high-performance FPGA logic that may be configured as distributed memory.

• Block RAM with a built-in FIFO for on-chip data buffering, 36 Kb, twin ports.

• High-speed SelectIOTM technology that is compatible with DDR3 connections of up to 1,866 Mb/s.

• High-speed serial communication with integrated multi-gigabit transceivers, providing a dedicated low-power mode that is suited for chip-to-chip interfaces, with maximum speeds ranging from 600 Mb/s to 6.6 Gb/s up to 28.05 Gb/s.

• A user-configurable analog interface (XADC) with dual 12-bit 1MSPS analog-to-digital converters with supply and heat sensors built right into the chip.

• DSP slices with an optimized symmetric coefficient filter and a 25 x 18 multiplier, 48-bit accumulator, and pre-adder for high-performance filtering.

XC7A15T-2CSG324I Applications

• Small Cell Baseband

• Professional Cameras

• Carrier Ethernet Backhaul

• Multi-function Printers

• Multi-Axis Motor Control

• Machine Vision

• Programmable Logic Controller

XC7A15T-2CSG324I Specifications
