The XC7A15T-L1CSG325I is an Artix-7 FPGA from AMD Xilinx. To guarantee a more coherent data flow, 150 I/Os in total are scheduled. The fundamental component of a computer is logic components or cells. A 0.95V-volt supply provides power. You can utilize this FPGA module with your development board by connecting the Surface Mount connector. FPGA devices can run at high speeds when supplied with a 0.95V–1.05V supply voltage. It is a specific FPGA type that is a part of the Artix-7 series. A temperature between -40°C and 100°C TJ must be maintained at all times to guarantee a safe and effective operation. This FPGA model is packed in Tray for space-saving purposes. There have been 325 terminations overall. It's important to note that this gadget has 921600 bfpga electronics s of RAM. This FPGA module has a maximum RAM si112.5kBe of 112.5kB, which is required to guarantee the smooth execution of the software. On this FPGA, 1300 LABs and CLBs are configured. This FPGA could operate flawlessly in accordance with its specifications as long as it is put in Surface Mount. View Substitutes & Alternatives, datasheets, stock, pricing from Authorized Distributors, as well as other FPGAs goods, at www.vemeko.com.
System Performance Improvement
Built on 28nm technology
MicroBlaze soft processor running over 200 DMIPs
Integrated ADC
Dedicated security features
Q-grade (-40°C to +125°C)
30% faster performance than 45nm generation devices
Up to 1.25Gb/s LVDS
25.6Gb/s peak DDR3-800 memory bandwidth
ADAS
Industrial
Consumer
Automotive
Defense and military
Medical Endoscope
Small Cell Baseband
Machine vision camera
Specification | Value |
Mounting Type | Surface Mount |
Package / Case | 324-LFBGA, CSPBGA |
Operating Temperature | -40°C~100°C TJ |
Packaging | Tray |
Published | 2010 |
Series | Artix-7 |
JESD-609 Code | e1 |
Part Status | Active |
Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
Number of Terminations | 325 |
HTS Code | 8542.39.00.01 |
Voltage - Supply | 0.95V~1.05V |
Supply Voltage | 0.95V |
Terminal Pitch | 0.8mm |
Number of I/O | 150 |
RAM Size | 112.5kB |
Number of Logic Elements/Cells | 16640 |
Total RAM Bits | 921600 |
Number of LABs/CLBs | 1300 |
