The AMD Xilinx XC7A35T-L2FTG256E is a Field Programmable Gate Array (FPGA) integrated circuit. 170 I/Os are available for better data transfer. 33280 logic cells/elements make comprise a basic building block. 0.9V is used as the supply voltage for fpga chips. This FPGA component is a programmable gate array and a member of the Field Programmable Gate Arrays family. This device includes 170 outputs in total. It has a total of 256 terminations in all. To make sure the program runs normally, the FPGA module's RAM si50kBe is increased to 50kB. There are 256 pins in all that are intended for it. This FPGA will function flawlessly in accordance with its specifications as long as it is put in Surface Mount. When used with a 900mV supply voltage, its flexibility is completely realized. A 0.9V power source is needed by fpga circuits in order for them to function. This module reaches a temperature of 100°C while operating at its maximum operational temperature. The operating temperature should be higher than 0°C. Fpga semiconductor has 256 pins and is equipped with Fpga semiconductor. The fundamental building component of the system is composed of 55650 logic blocks (LABs). One of the most typical parts of this gadget is a crystal oscillating at 1098MHz. It can receive a maximum voltage of 3.465V. Fpga semiconductors can operate with 920mV as their bare minimum supply voltage. Additionally to having the feature ALSO OPERATES AT 1V SUPPLY, it also has the feature A. View Substitutes & Alternatives, datasheets, stock, pricing from Authorized Distributors, as well as other FPGAs goods, at www.vemeko.com.
Multiple USB cable connections are no longer necessary thanks to the onboard USB hub.
PCB has mounting holes that are typical for the PC/104 form factor.
Powered by a USB header or a 5 V external DC adapter connected to a barrel jack.
Automatic USB and external power switching; external reception is preferred
The NCP380 load switch lowers inrush current and limits USB current to 2 amps.
Quad-SPI 16 MB Spansion Flash
Circuitry for USB-JTAG programming
UART-USB bridge
A single Zmod standard SYZYGY port
Three Pmod standard ports
IP and Smart camera
Video and night vision equipment
LTE radio and baseband
Multifunction printers
Flat Panel Displays
Set-Top Boxes
Wireless Access
Industrial Ethernet and Motion Control
Specification | Value |
Mount | Surface Mount |
Package / Case | FBGA |
Number of Pins | 256 |
Number of Terminations | 256 |
Max Operating Temperature | 100°C |
Min Operating Temperature | 0°C |
Subcategory | Field Programmable Gate Arrays |
Supply Voltage | 0.9V |
Terminal Pitch | 1mm |
Pin Count | 256 |
Number of Outputs | 170 |
Operating Supply Voltage | 900mV |
Power Supplies | 0.9V |
Max Supply Voltage | 3.465V |
Min Supply Voltage | 920mV |
Number of I/O | 170 |
RAM Size | 50kB |
Clock Frequency | 1098MHz |
Propagation Delay | 850 ps |
Number of Logic Elements/Cells | 33280 |
Number of Logic Blocks (LABs) | 55650 |
Speed Grade | 2 |
Combinatorial Delay of a CLB-Max | 1.51 ns |
Max Junction Temperature (Tj) | 100°C |
