XC7A75T-1CS324I is bundled with the 324-LFBGA, CSPBGA package. For more effective data transport, 210 I/Os are available. There are 75520 logic elements or cells in a basic construction block. The FPGA module can be attached to the development board via the Surface Mount-slot. Fpga chips require a supply voltage of 0.95V–1.05V to operate. It is a specific FPGA subtype from the Artix-7 series. Operating temperatures should be kept between -40°C and 100°C TJ while in use. This FPGA model can fit inside a very small area using the Bulk layout. The fpga chip's available RAM bits total 3870720. An array of 5900 latches, or CLBs, make up the FPGA. One of its suppliers is the device package provided by 324-CSPBGA (15x15). View Substitutes & Alternatives, datasheets, stock, pricing from Authorized Distributors, as well as other FPGAs goods, at www.vemeko.com.
16-bit bus, 512 MB micron DDR3, 800 or 667 MT/s, adjustable voltage
Multiple USB cable connections are no longer necessary thanks to the onboard USB hub.
Three Pmod standard ports
Reduction in total power (65% less static power and 50% less power than 45nm generation devices)
Modern 28nm, high-k metal gate (HKMG), high performance, low power (HPL) technology
Options for lidless flip-chip packages, low cost wire bonding, and AXI IP (analogue mixed signal integration)
Powered by a USB header or a 5 V external DC adapter connected to a barrel jack.
The NCP380 load switch lowers inrush current and limits USB current to 2 amps.
Circuitry for USB-JTAG programming
A single Zmod standard SYZYGY port
Consumer electronics
Medical devices
Automotive
Embedded vision
Software defined radio
Portable ultrasound
ADAS
Small Cell Baseband
Specification | Value |
Category | Integrated Circuits (ICs) Embedded FPGAs (Field Programmable Gate Array) |
Mfr | AMD |
Series | Artix-7 |
Package | Bulk |
Product Status | Active |
DigiKey Programmable | Not Verified |
Number of LABs/CLBs | 5900 |
Number of Logic Elements/Cells | 75520 |
Total RAM Bits | 3870720 |
Number of I/O | 210 |
Voltage - Supply | 0.95V ~ 1.05V |
Mounting Type | Surface Mount |
Operating Temperature | -40°C ~ 100°C (TJ) |
Package / Case | 324-LFBGA, CSPBGA |
Supplier Device Package | 324-CSPBGA (15x15) |
Base Product Number | XC7A75 |
