The AMD Xilinx Spartan®-7 XC7S50-2CSGA324I is an embedded field-programmable gate array (FPGA) with 210 I/Os. The device has 52160 logic cells and 4075 LABs/CLBs. It has a voltage supply range of 0.95V to 1.05V with a total RAM size of 2764800 bits. The gadget has an SMD (SMT) mounting and is packaged in a tray. The 324-LFBGA, CSPBGA package/case has a supplier device package of 324-CSPBGA (15x15). The hardware is identified by the ECCN 3A991D and the HTSUS 8542.39.0001. The MSL level is 3 (168 hours) and there is a 66 percent false danger in the open market. The instrument can withstand temperatures between -40°C and 100°C (TJ). View Substitutes & Alternatives, datasheets, stock, pricing from Authorized Distributors, as well as other FPGAs goods, at www.vemeko.com.
MicroBlaze™ processor
36 Kb dual-port block RAM
Real 6-input lookup table (LUT)-based advanced high-performance FPGA logic that may be configured as distributed memory.
Block RAM with a built-in FIFO for on-chip data buffering, 36 Kb, twin ports.
High-performance SelectIO™ technology
Integrated PCI Express® (PCIe) block
Powerful clock management tiles (CMT)
Dual 12-bit 1MSPS analog-to-digital converters
IP and Smart camera
LTE radio and baseband
Multi-function Printers
Multi-Axis Motor Control
Automotive driver assistance
Medical diagnostics and imaging
Specification | Value |
Category | Integrated Circuits (ICs) Embedded FPGAs (Field Programmable Gate Array) |
Mfr | AMD |
Series | Spartan®-7 |
Package | Tray |
Product Status | Active |
DigiKey Programmable | Not Verified |
Number of LABs/CLBs | 4075 |
Number of Logic Elements/Cells | 52160 |
Total RAM Bits | 2764800 |
Number of I/O | 210 |
Voltage - Supply | 0.95V ~ 1.05V |
Mounting Type | Surface Mount |
Operating Temperature | -40°C ~ 100°C (TJ) |
Package / Case | 324-LFBGA, CSPBGA |
Supplier Device Package | 324-CSPBGA (15x15) |
Base Product Number | XC7S50 |
