XC73108-7PC84C
Utilizing a novel Dual-Block architecture, the XC73108-7PC84C family offers high density capabilities through High Density Function Blocks and/or high speed operations through Fast Function Blocks. Additionally, the Universal Interconnect Matrix (UIM) is used in the XC73108-7PC84C architecture, ensuring 100% interconnectivity of all internal processes.The XC73108-7PC84C devices come in pin-grid-array (PGA), ball-grid-array (BGA), and quad flat pack (QFP) packaging, as well as plastic and ceramic leaded chip carriers. Package options range from windowed ceramic for design prototypes to one-time programmable plastic versions for low-cost mass production. View Substitutes & Alternatives, datasheets, stock, pricing from Vemeko, as well as other FPGAs goods, at www.vemeko.com.
Every input can be set to be registered, latched, or direct.
24 mA high-drive output with 3.3 V or 5 V I/O operation
3.3 V ±0.3 V JEDEC Standard (8-1A) is met.
Options for power control
Several security components to safeguard designs
Equipped with design and verification tools that are industry standard
PCI compliance is 100%
ADAS
Medical Endoscope
Small Cell Baseband
Professional Cameras
Machine Vision
Carrier Ethernet Backhaul
Multi-function Printers
Multi-Axis Motor Control
Product information on this page is provided for identification and sourcing reference purposes. A product listing does not indicate that VEMEKO currently holds physical inventory of the listed part number. Availability, manufacturer, source, date code, packaging, condition and lead time are confirmed separately at the quotation stage.
AMD, Xilinx, Zynq, Kintex, Virtex and other related trademarks are the property of Advanced Micro Devices, Inc. or its affiliates. VEMEKO is an independent electronic component sourcing company and is not represented as an authorized distributor of AMD unless expressly stated and documented for a specific transaction.
| Specification | Value |
| HTS Code | 8542.39.00.01 |
| Ihs Manufacturer | XILINX INC |
| Length | 29.3116 mm |
| Manufacturer Part Number | XC73108-7PC84C |
| Manufacturer | Xilinx |
| Number of Terminals | 84 |
| Operating Temperature-Max | 70 °C |
| Organization | 12 DEDICATED INPUTS, 37 I/O |
| Output Function | MACROCELL |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | QCCJ |
| Package Description | PLASTIC, LCC-84 |
| Package Shape | SQUARE |
| Package Style | CHIP CARRIER |
| Part Life Cycle Code | Obsolete |
| Part Package Code | LCC |
| Pin Count | 84 |
| Reach Compliance Code | unknown |
| Risk Rank | 5.81 |
| Rohs Code | No |
| Subcategory | Programmable Logic Devices |
| Supply Voltage-Max | 5.25 V |
| Supply Voltage-Min | 4.75 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | COMMERCIAL |
